12 │ About your monitor
Bottom view
Bottom view without monitor stand
Label Description Use
1 Security-lock slot Secure your monitor using a security lock
(purchased separately) to prevent unauthorized
movement of your monitor.
2 Power connector Connect the power cable (shipped with your
monitor).
3 HDMI port Connect to your computer using a HDMI cable
(shipped with your monitor, for Brazil only).
4 Stand lock To lock the stand to the monitor using a M3 x 6
mm screw (screw not included).
5 DisplayPort Connect to your computer using a DisplayPort
cable (shipped with your monitor).
6 VGA connector Connect your computer with VGA cable.
7 SuperSpeed USB 5
Gbps (USB 3.2 Gen1)
upstream port
Connect the USB cable (shipped with your
monitor) from this port to your computer to
enable the USB ports on your monitor.
8 SuperSpeed USB 5
Gbps (USB 3.2 Gen 1)
Type-A downstream
port (4)
Connect your USB devices.*
NOTE: To use this port, you must
connect the USB upstream cable
(shipped with your monitor) between the
monitor and the computer.
*To avoid signal interference, when a wireless USB device has been connected
to a USB downstream port, it is NOT recommended to connect any other USB
devices to the adjacent port(s).
