Dell P3221D - Using the Tilt, Swivel, and Vertical Extension; Tilt, Swivel and Vertical Extension; Rotating the Monitor

Setting up the monitor | 29
Using the tilt, swivel, and vertical extension
NOTE: The following instructions are applicable only for the stand that
was shipped with your monitor. If you are connecting a stand that you
purchased from any other source, follow the set up instructions that were
included with the stand.
Tilt, swivel and vertical extension
With the stand attached to the monitor, you can tilt the monitor for the most
comfortable viewing angle.
5°
30°
30°
150 mm
21°
NOTE: The stand is detached when the monitor is shipped from the
factory.
Rotating the monitor
Before you rotate the monitor, your monitor should be fully vertically extended and fully
tilted up to avoid hitting the bottom edge of the monitor.
2
1
90°
90°
