Dell P3221D User Manual

About your monitor | 7
DP cable
Cable Tie
Dell P3221D
USB Type-C
(C-C)
USB Type-C
(C-A)
DP
Dell P3221D
USB Type-C
(C-C)
USB Type-C
(C-A)
DP
HDMIDPUSBUSB
USB Type-C
HDMIUSB Type-C
DisplayPort
HDMI
USB
DisplayPort
3
HDMIDPUSBUSB
USB Type-C
USB Type-C
USB Type-C
746.06E01.0001
(DELL P/N: Y64RY rev.X00)
© 2020 Dell Inc. or its subsidiaries.
2020-07
i
www.dell.com/contactdell
6
1
2
3
i
Dell.com/P3221D
4
2
1
1 2
3
1 2
2
1
5
i
1
2
3
4
HDMI
HDMI DP USB USB
USB Type-C
HDMI USB Type-C
DisplayPort
HDMI
USB
DisplayPort
3
HDMI DP USB USB
USB Type-C
USB Type-C
USB Type-C
746.06E01.0001
(DELL P/N: Y64RY rev.X00)
© 2020 Dell Inc. or its subsidiaries.
2020-07
i
www.dell.com/contactdell
6
1
2
3
i
Dell.com/P3221D
4
2
1
1
2
3
1 2
2
1
5
i
•Quick Setup Guide
•Safety, Environmental, and
Regulatory Information
NOTE: USB Type-C
®
and USB-C
®
are registered trademarks of USB
Implementers Forum.
Product features
The P3221D monitor has an active matrix, Thin Film Transistor (TFT), Liquid Crystal
Display (LCD), and LED backlight. The monitor features include:
• P3221D: 80.1 cm (31.5 in.) active area display (Measured diagonally) 2560 x 1440
(16:9) resolution, plus full-screen support for lower resolutions.
• Wide viewing angles with 99% sRGB color.
• Tilt, swivel, pivot and vertical extension adjustment capabilities.
• Removable pedestal and Video Electronics Standards Association (VESA™) 100
mm mounting holes for flexible mounting solutions.
• Ultra-thin bezel minimizes the bezel gap in multi-monitor usage, enabling easier
set up with an elegant viewing experience.
• Extensive digital connectivity with DP and HDMI helps future-proof your monitor.
• Plug and play capability if supported by your system.
• On-Screen Display (OSD) adjustments for ease of set-up and screen
optimization.
• Power and OSD buttons lock.
• Security lock slot.
• 0.3 W standby power when in the sleep mode.
• Optimize eye comfort with a flicker-free screen.
WARNING: The possible long-term effects of blue light emission from the
monitor may cause damage to the eyes, including eye fatigue or digital eye
strain. ComfortView feature is designed to reduce the amount of blue light
emitted from the monitor to optimize eye comfort.

Dell P3221D Specifications

General

Pixel pitch	0.2727 x 0.2727 mm
Screen shape	Flat
Pixel density	93.24 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	31.5 \
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	56 - 76 Hz
Maximum refresh rate	60 Hz
Response time (fast)	5 ms
Horizontal scan range	30 - 90 kHz
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1440p
Viewable size diagonal	800.98 mm
Viewable size, vertical	392.688 mm
Display number of colors	1.07 billion colors
Viewable size, horizontal	698.112 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1280 x 800, 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2048 x 1080, 2560 x 1440
HDMI	Yes
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-C
USB Type-A downstream ports quantity	4
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 21 °
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	145 W
Power consumption (standby)	0.2 W
Power consumption (typical)	25.1 W
Power consumption (PowerSave)	20.6 W
Package depth	177 mm
Package width	940 mm
Package height	525 mm
Package weight	15600 g
Feet color	Silver
Product color	Black
Market positioning	Business
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	7.5 mm
Bezel width (side)	7.6 mm
Depth (with stand)	230 mm
Width (with stand)	713.4 mm
Height (with stand)	618.8 mm
Weight (with stand)	10700 g
Bezel width (bottom)	17.9 mm
Depth (without stand)	55.3 mm
Height (without stand)	418 mm
Weight (without stand)	6400 g
