Dell P5524Q - Page 31

Operating the monitor | 31
Icon Menu and
submenus
Description
Input Source Use the Input Source menu to select between dierent
video signals that may be connected to your monitor.
Color
Others
Personalize
Menu
Brightness/Contrast
Dell 55 Monitor
Auto Adjust
Input Source
Auto Select On
VGA
DP
HDMI 1
HDMI 2
Reset Input Source
Display
Audio
VGA Select VGA input when you are using the analog (VGA)
connector. Push to select the VGA input source.
DP Select DisplayPort input when you are using the
DisplayPort (DP) connector. Push to select the
DisplayPort input source.
HDMI 1 Select HDMI 1 input when you are using the HDMI 1
connectors. Press to select the HDMI 1 input source.
HDMI 2 Select HDMI 2 input when you are using the HDMI 2
connectors. Press to select the HDMI 2 input source.
Auto Select Select Auto Select to scan for available input signals.
Reset Input
Source
Resets your monitor’s input source to the factory defaults.
