Next steps
1. Replace the battery cable.
2. Replace the base cover
3. Replace the SD memory card
4. Follow the procedure in after working inside your computer
Removing the M.2 2230 Solid-state drive
Prerequisites
1. Follow the procedure in before working inside your computer
2. Remove the SD memory card
3. Remove the
base cover
4. Disconnect the battery
cable
Steps
1. Remove the single (M2x3) screw that secures the thermal plate to the palmrest and keyboard assembly [1].
2. Turn the thermal plate over [2].
3. Slide and remove the thermal plate from the solid-state drive slot [3].
Removing and installing components 51
