NOTE: M.2 2230 solid-state drive thermal bracket illustrated
4. Solid-state drive 1
NOTE: M.2 2230 solid-state drive illustrated
5. Right fan
6. Display-cable bracket
7. USB Type-C port bracket
8. System board
9. Memory module
10. Right antenna
11. Palm-rest and keyboard assembly
12. Display assembly
13. Left antenna
14. Solid-state drive 2
NOTE: M.2 2280 solid-state drive illustrated
15. Solid-state drive 2 thermal bracket
NOTE: M.2 2280 solid-state drive thermal bracket illustrated
16. I/O board
17. USB Type-C port bracket
18. Left fan
19. Heat sink
NOTE:
Dell provides a list of components and their part numbers for the original system configuration purchased. These
parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for
purchase options.
Base cover
Removing the base cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
About this task
The following images indicate the location of the base cover and provide a visual representation of the removal procedure.
12
Removing and installing components
