Table 1. Screw list (continued)
Component Secured to Screw type Quantity Screw image
Antenna (right) Palm-rest and
keyboard assembly
M2x2 4
Wireless-card bracket System board M2x4 1
USB-port bracket (left) Palm-rest and
keyboard assembly
M2x4 2
USB-port bracket (right) Palm-rest and
keyboard assembly
M2x4 2
Major components of XPS 17 9710
The following image shows the major components of XPS 17 9710.
10 Removing and installing components
