Dell PowerConnect 2216 - Figure 1-2. Powerconnect 2224; Figure 1-3. Powerconnect 2324

8 Introduction
www.dell.com | support.dell.com
Figure 1-2. PowerConnect 2224
Figure 1-3. PowerConnect 2324
RJ-45 ports
FDX/HDX LEDs
SPD/LNK/ACT LEDs
power LED
RJ-45 ports
power LED
FDX/HDX LEDs
SPD/LNK/ACT LEDs
