32 PowerConnect B-Series FCX Web Management Interface User Guide
53-1002268-01
Monitoring the management port
3
Monitoring the management port
Select Monitor > Port > Management to view the current management port configuration details.
FIGURE 25 Monitoring management port configuration
The Management Port Configuration contains the following information.
Click on any of the management port will open the realtime information for that port.
Port Name of the management port. Each entry has a link to detailed realtime information
about the port.
Actual speed mode Shows whether the actual speed matches the configured speed. If the configured
speed is set to Auto, then the speed is provided.
Configured speed mode The speed duplex set for the port.
Modify Allows you to configure a management port or change the configuration of a current
management port.
