Dell PowerEdge C6100

38 Using the Baseboard Management Controller
www.dell.com | support.dell.com
Threshold Settings and Converting Formulas
Table 1-33. Threshold Settings and Converting Formulas
Sensor
Number
Sensor Name The Converting Formula
Upper non-
recoverable
Upper
critical
Upper
non-critical
Lower non-
recoverable
Lower
critical
Lower
non-critical
Fan
01h FCB FAN1 Actual_Reading (RPM) = Raw_Data x 100
0xFF 0xFF 0xFF 0x00 0x0F 0x00
02h FCB FAN2 Actual_Reading (RPM) = Raw_Data x 100
0xFF 0xFF 0xFF 0x00 0x0F 0x00
03h FCB FAN3 Actual_Reading (RPM) = Raw_Data x 100
0xFF 0xFF 0xFF 0x00 0x0F 0x00
04h FCB FAN4 Actual_Reading (RPM) = Raw_Data x 100
0xFF 0xFF 0xFF 0x00 0x0F 0x00
Voltage
14h PS 12V Actual_Reading (Volts) = Raw_Data x 0.062
0xD8 0xD4 0xCF 0xAB 0xAF 0xB4
15h PS 5V Actual_Reading (Volts) = Raw_Data x 0.026
0xD7 0xD3 0xCD 0xA9 0xAE 0xB3
16h STBY 3.3V Actual_Reading (Volts) = Raw_Data x 0.0172
0xD6 0xD3 0xCD 0xA9 0xAD 0xB3
51h VCORE 1 Actual_Reading (Volts) = Raw_Data x 0.0083
0xFF 0xFF 0xFF 0x00 0x00 0x00
