24 PowerEdge C6220 Technical Guide
The PowerEdge C6220 does not support hot-pluggable PCIe cards.
Table 12 lists the supported mezzanine and add-in cards.
Table 12. Supported mezzanine and add-in cards
Card type
Interface
LSI 2008 8-port SAS (supported only at 3Gbps)
Mezzanine slot
Mellanox ConnectX-2 dual-port QDR InfiniBand
Mezzanine slot
Mellanox ConnectX-3 single-port FDR InfiniBand
Mezzanine slot
Intel 82599 dual-port 10GbE (SFP+)
Mezzanine slot
Intel 82580 quad-port 1GbE
Mezzanine slot
QLogic single-port QDR InfiniBand QLE7340
Riser slot
LSI 9265-8i (supported only at 3Gbps)
Riser slot
LSI 9210-8i (supported only at 3Gbps)
Riser slot
LSI 9285-8e
Riser slot (available via CUST kit only)
Intel i350 quad-port 1Gb
Riser slot
Dell X410 HIC card
Riser slot
Intel X520-DA dual-port 10GbE (SFP+)
Riser slot
Intel X540 dual-port 10GbE Base-T
Riser slot (available via CUST kit or S&P
NIC cards
Table 13 lists the supported NIC add-in cards.
Table 13. Supported NIC add-in cards
Card type
Interface
Intel 82559 dual-port 10GbE (SFP+)
PCIe x8 mezzanine slot
Intel 82580 quad-port 1GbE
PCIe x8 mezzanine slot
Mellanox Connect X-2 dual-port QDR IB
Mezzanine slot
Mellanox Connect X-3 single-port FDR IB
Mezzanine slot
Intel i350 1Gb quad-port
Riser slot
Intel X520-DA dual-port 10GbE (SFP+)
Riser slot
Intel X540 dual-port 10GbE Base-T
Riser slot (validated only)
For the latest information on PowerEdge C6220-supported PCIe expansion cards, visit
Dell.com/PowerEdgeC.
