18 About Your System
4 iDRAC6 Enterprise port
(optional)
Dedicated management port for the
optional iDRAC6 Enterprise card.
5 USB connectors (2) Connects USB devices to the system.
The ports are USB 2.0-compliant.
6 Ethernet connectors (2) Embedded 10/100/1000 NIC
connectors.
7 PCIe slot 1 PCI Express (Generation 2) x16-wide
expansion slot (full-height,
half-length).
8Active ID CMA
connector
Connector for attaching a system
indicator extension cable that is used
on a cable management arm.
9 System status indicator Lights blue during normal
system operation.
Lights amber when the system needs
attention due to a problem.
10 System identification
button
The identification buttons on the front
and back panels can be used to locate a
particular system within a rack. When
one of these buttons is pushed, the
LCD panel on the front and the system
status indicator on the chassis back
panel light blue until one of the
buttons is pushed again.
11 Power supply 1(PS1) 500 W power supply (redundant).
12 Power supply 2(PS2) 500 W power supply (redundant) or
480 W power supply (non-redundant).
Item Indicator, Button, or
Connector
Icon Description
