80 Installing System Components
Figure 3-1. Inside the System
1 power supply shroud 2 system board shroud
3 power supply bay (2) 4 expansion-card riser
5 heat sink/processor (2) 6 memory module (8)
7 system cooling fan (4) 8 optical drive
9 hard-drive (4) 10 control panel board
11 SAS backplane 12 power supply cooling fan (2)
2
1
4
7
9
3
8
5
6
10
11
12
