86 Installing System Components
If the drive has been online, the green activity/fault indicator flashes as the
drive is powered down. When the drive indicators are off, the drive is ready
for removal.
3
Press the release button on the front of the hard-drive carrier and open the
handle.
4
Slide the hard-drive carrier out until it is free of the drive bay. See
Figure 3-5.
CAUTION: To maintain proper system cooling, all empty hard-drive bays must
have drive blanks installed.
5
Insert a drive blank in the empty drive bay. See "Installing a Hard-Drive
Blank" on page 85.
6
If applicable, install the front bezel. See "Installing the Front Bezel" on
page 81.
Figure 3-5. Removing and Installing a Hard-Drive Carrier
1 release button 2 hard-drive carrier handle
3 hard-drive carrier
R415HOM.book Page 86 Friday, September 24, 2010 9:37 AM
