PowerEdge T310 Technical Guide 14
4 Mechanical
4.1 Chassis Description
The PowerEdge T310 chassis design provides capability for hardware redundancy. This new chassis
design offers cabled HDD with flexible PSU (redundant PSU or non-redundant PSU) and Hot-Plug HDD
with flexible PSU (redundant PSU or non-redundant PSU). Various configurations are available.
However, customers cannot upgrade from a Cabled, non-redundant chassis to a Hot-Plug, Redundant
PSU version.
The PowerEdge T310 chassis is user friendly. Many of the T310 component devices are tool-less, for
example, HDDs (cabled and hot-plug), fans, extension cards, planar, backplane, and redundant PSUs.
The non-redundant PSU uses only three screws to reduce the assembly and service time.
4.2 Dimensions and Weight
Figure 1. PowerEdge T310 Dimensions
Table 3. Dimensions and Weight
Height
44 cm (17.3 inch)
Width
21.8 cm (8.58 inch)
Depth
52.1 cm (20.5 inch)
Weight (maximum
configuration)
23.5 kg (51.8 lb)
