Installing System Components 143
5
To disconnect the control panel cable from the connector on the
system board:
a
Squeeze the metal tabs on the ends of the cable connector.
See Figure 3-26.
b
Gently pull the connector out of the socket.
6
Using a Phillips screwdriver, remove the screw that secures the control
panel assembly to the chassis. See Figure 3-26.
7
Press the release latch and slide the control panel away from chassis.
CAUTION: Do not pull the cable to unseat the connector. Doing so can damage
the cable.
8
To disconnect the control panel cable from the connector on the control
panel board:
a
Squeeze the metal tabs on the ends of the cable connector.
See Figure 3-26.
b
Gently pull the connector out of the socket.
book.book Page 143 Tuesday, June 9, 2009 4:09 PM
