Installing System Components 95
3 Press the button on the front of the drive carrier to release the carrier
handle. See Figure 3-7.
4 Rotate the carrier handle to extract the drive from the bay.
5
Slide the hard drive out until it is free of the drive bay.
6
Remove the four screws that secure the hard drive to the hard-drive carrier.
7
Remove the hard drive from the carrier.
8
Insert a drive blank in the vacated drive bay. See "Installing a Drive Blank
in the Front Bay" on page 94.
CAUTION: To maintain proper system cooling, all empty hard-drive bays must
have drive blanks installed.
Figure 3-7. Removing and Installing a Hot-Swap Hard Drive
1 release button 2 hard drive carrier handle
