220 Management: Installing Array Components

Connect all the power cables to the array.

Turn on the array and the host server.

Figure 16-7. Removing and Installing a RAID Controller Module Blank

Installing a RAID Controller Module Blank

To install a RAID controller module blank:

Align the blank with the RAID controller module bay

Insert the blank into the chassis until it clicks into place.

1 release latch 2 RAID controller module blank

1 2

book.book Page 220 Saturday, September 24, 2011 9:06 AM
