Planning: About Your Storage Array 27

Back Panel Features and Indicators

Figure 2-4. Back-Panel Features and Indicators—Dell PowerVault MD3200i Series

1 600 W power supply/cooling fan

module

2 RAID Controller Module 0

3 RAID Controller Module 1 4 600 W power supply/cooling fan

module

book.book Page 27 Saturday, September 24, 2011 9:06 AM
