Control Panel
Removing the Control Panel
1 Turn off the array and host server.
2 Disconnect all the power cables connected to the array.
3 Remove the hard drives from:
– slots 0 to 2 in
PowerVault MD3200i
– slots 0 to 5 in
PowerVault MD3220i
See "Removing a Hard Drive" on page 214.
NOTE: Mark each hard drive with it’s slot position as you remove it.
4 Slide the control panel out of the chassis after:
– Pushing the release tab toward the front of the array in
PowerVault
MD3200i
. See Figure 16-13.
– Pulling the release pin toward the front of the array in
PowerVault
MD3220i
. See Figure 16-14.
Figure 16-13. Removing and Installing the Control Panel-PowerVault MD3200i
1 control panel 2 release tab
