Planning: About Your Storage Array

Overview

The MD3200i Series storage array is designed for high availability, offering

redundant access to data storage. It features support for both single and dual

RAID controller configuration.

The Dell PowerVault MD3200i storage array provides 1.0-Gbps 1000 BaseT

connectivity to the host server and enables access to 32 physical hosts.

The MD3200i Series storage array includes:

• RAID controller module(s)

•PSU/Fan modules

• Disk drives (also called physical disk drives in this document)

• A front bezel (optional)

• A system enclosure, into which, the other components are plugged
