30 Using Your NAS System
4
Go to the
UNM
server, copy the password, and group the files you
collected in the previous step to a local disk.
5
Go to
Add or Remove Programs
Add Windows Components
Select
Other Network File and Print Services
.
6
Click
Details
.
7
Select
Microsoft Services for NFS
, click
Details
and select
User Name
Mapping
.
8
Click
Next
and complete the installation.
NOTE: Reboot your system after the installation is complete.
Configuration Steps
1
Go to the
NFS client,
obtain the
/etc/passwd
and
/etc/group files
and copy
them to a USB key.
2
Go to the UNM server and copy the UNIX files from the USB key to a local
hard disk. Open
Microsoft Services for NFS
.
3
Select
User Name Mapping
and then
right-click
Properties
.
4
Go to
UNIX User Source
tab and select the
Use Password and Group Files
option.
5
Click the
Browse
button, select the password and group files that you had
copied in the previous step.
6
Go to the
Simple Mapping
tab, select the
Use simple maps
option, and
click
Apply
.
7
Select
User Maps,
and right-click
Create Map
.
8
Click
List Windows Users
and
List UNIX Users
options. Map the users
(select one user at a time) and add to the list. Repeat this step for other
listed users.
9
Open
Group Maps
Create Maps
.
10
List
Windows & Unix groups,
map them and add to the list.
Open the .maphosts file (C:\Windows\msnfs and
C:\Windows\amd64\cmpnents\r2 and look for the .maphosts file) and add
the NFS server details (IP 4 address or host name, if DNS exists) and save the
file.
