Removing the WLAN card
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
3. To remove the WLAN card:
a. Remove the screw that secures the metal bracket to the WLAN card [1].
b. Remove the metal bracket [2].
c. Disconnect the WLAN cables from the connectors on the WLAN card [3].
d. Unroute the WLAN cables from the routing channel.
e. Remove the WLAN card from the computer [4].
Installing the WLAN card
1. Insert the WLAN card into the slot on the computer.
2. Route the WLAN cables through the routing channel.
3. Connect the WLAN cables to the connectors on the WLAN Card.
4. Place the metal bracket and tighten the screw to secure it to the computer.
5. Install the:
a. battery
b. base cover
6. Follow the procedure in After working inside your system.
Removing the WWAN card
1. Follow the procedure in Before working inside your computer.
2. Remove the:
