2. Remove the SIM card.
3. Remove the microSD card.
4. Remove the base cover.
5. Remove the 2280 solid-state drive or 2230 solid-state drive.
6. Remove the battery.
7. Remove the hard drive.
8. Remove the wireless card.
9. Remove the WWAN card.
10. Remove the assembly inner frame.
11. Remove the system board.
NOTE: The system board can be removed with the heat sink attached in order to simplify the procedure and preserve
the thermal bond between the system board and heat sink.
About this task
The following images indicate the location of the keyboard assembly and provide a visual representation of the removal
procedure.
