Dell Precision 7730 - Speaker; Removing the Speakers

2. Install the:
a. palmrest
b. base cover
c. hard drive
d. keyboard
e. battery
f. battery cover
g. SD card
3. Follow the procedure in After working inside your computer.
Speaker
Removing the speakers
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. SD card
b. battery cover
c. battery
d. keyboard
e. hard drive
f. base cover
g. palmrest
3. To remove the speaker:
a. Disconnect the speaker cable from the system board [1].
b. Unroute the speaker cable and remove the cable from the routing channels.
c. Lift the speakers, along with the speaker cable and remove it away from the system [2].
66
Removing and installing components
