Dell Precision 7730 User Manual

NOTE: Ensure that the computer and all attached devices are turned off. If your computer and attached devices did not
automatically turn off when you shut down your operating system, press and hold the power button for about 6 seconds
to turn them off.
Before working inside your computer
1. Ensure that your work surface is flat and clean to prevent the computer cover from being scratched.
2. Turn off your computer.
3. If the computer is connected to a docking device (docked), undock it.
4. Disconnect all network cables from the computer (if available).
CAUTION: If your computer has an RJ45 port, disconnect the network cable by first unplugging the cable
from your computer.
5. Disconnect your computer and all attached devices from their electrical outlets.
6. Open the display.
7. Press and hold the power button for few seconds, to ground the system board.
CAUTION: To guard against electrical shock unplug your computer from the electrical outlet before
performing Step # 8.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by
periodically touching an unpainted metal surface at the same time as touching a connector on the back
of the computer.
8. Remove any installed ExpressCards or Smart Cards from the appropriate slots.
After working inside your computer
After you complete any replacement procedure, ensure that you connect external devices, cards, and cables before turning on
your computer.
CAUTION:
To avoid damage to the computer, use only the battery designed for this particular Dell computer. Do
not use batteries designed for other Dell computers.
1. Connect any external devices, such as a port replicator or media base, and replace any cards, such as an ExpressCard.
2. Connect any telephone or network cables to your computer.
CAUTION:
To connect a network cable, first plug the cable into the network device and then plug it into the
computer.
3. Connect your computer and all attached devices to their electrical outlets.
4. Turn on your computer.
8
Working on your computer

Dell Precision 7730 Specifications

General

Bus type	DMI
Tjunction	100 °C
Processor cache	9 MB
Processor cores	6
Processor model	i7-8850H
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor socket	BGA 1440
Processor threads	12
Processor codename	Coffee Lake
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4.3 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	45 W
Configurable TDP-down frequency	2.1 GHz
Maximum number of PCI Express lanes	16
On-board graphics card	Yes
On-board graphics card ID	0x3E9B
Discrete graphics card model	AMD Radeon Pro WX 4150
On-board graphics card model	Intel® UHD Graphics 630
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® UHD Graphics
Maximum on-board graphics card memory	64 GB
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
Number of discrete graphics cards installed	1
On-board graphics card dynamic frequency (max)	1150 MHz
Form factor	Clamshell
Product type	Mobile workstation
Product color	Black
Market positioning	Business
Pixel density	127 ppi
Display surface	Matt
Display diagonal	17.3 \
Display brightness	300 cd/m²
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Contrast ratio (typical)	700:1
Memory slots	4x SO-DIMM
Internal memory	16 GB
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	128 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Total storage capacity	512 GB
Compatible memory cards	SD, SDHC, SDXC
Audio chip	Realtek ALC3281
Speaker power	2 W
Number of built-in speakers	2
Front camera HD type	HD
Video capturing speed	30 fps
Front camera resolution	1280 x 720 pixels
Front camera signal format	720p
Front camera resolution (numeric)	0.92 MP
Antenna type	-
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Processor ARK ID	134899
Processor package size	42 x 28 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19.5 V
Cable lock slot type	Noble
Password protection type	BIOS, User
Operating system installed	Windows 10 Pro for Workstations
Motherboard chipset	Intel® CM246
Battery recharge time	4 h

Weight and Dimensions

Depth	273.7 mm
Width	414.2 mm
Weight	3090 g
Height (rear)	30.22 mm
Height (front)	26.15 mm
