Installing the power connector port
1. To install the power connector port:
a. Connect the power connector port to the system [1].
b. Place the power connector cable metal bracket [2].
c. Replace the single (M2.0x3.0) screw to secure the metal bracket to the system [3].
Removing and installing components
53
