c. Connect the eDP cable to the connector on the system board and affix the adhesive tape to secure the eDP cable in
place [1].
d. Place and align the display cable bracket above the eDP cable connector [2].
e. Replace the single (M2.0x3.0) screw to secure the eDP cable bracket to the system board [3].
f. Connect the two fan cables to the connector on the system board [4, 5].
74
Removing and installing components
