Dell PRECISION PP18L - Back View; Bottom View

Quick Reference Guide 13
Back View
Bottom View
1 network
connector (RJ-45)
2 modem connector
(RJ-11)
3USB
connectors (2)
4 serial
connector
5 video connector 6 AC adapter
connector
7 air vents
1 battery charge
gauge/health gauge
2 battery 3 battery-bay latch
releases (2)
4 device locking screw
(if present)
5 memory module cover 6 docking-device
connector
7 air vents 8 hard drive 9 hard drive screws (2)
1 2 63 4 75
7
6
1
5
2
8
3
4
9
