Dell PRECISION T1650 Technical Guidebook

TABLE OF CONTENTS
OVERVIEW
External Chassis Views 3
Motherboard Layout 4
MARKETING SYSTEM CONFIGURATIONS
Operating System, Chipset 5
Processor 6
Memory 7
Graphics/Video Controllers 8
Drives and Removable Storage 9
System Expansion Slots, External Ports/Connectors 10-11
Hard Drive Controller, Communications—Network Adapter, Audio and Speakers, Keyboard and Mouse 11
Security, Service and Support, Software 12
DETAILED ENGINEERING SPECIFICATIONS
System Dimensions (Physical), System Expansion Slots 13
System Level Environmental and Operating Conditions, Power 14-15
Audio—Integrated, Communications– Integrated LAN 16-17
Communications—Add in Network Interface Card (NIC) 17
Communications—Add in 1394 card, Add in Parallel / Serial Card 18
Graphics/Video Controllers 19-25
Hard Drives 26-35
Optical Drive 34-35
Media Card Reader 36
BIOS Defaults 37
Chassis Enclosure and Ventilation Requirements 38
ADDITIONAL INFORMATION
Statement of Volatility (SOV) 39-41

Dell PRECISION T1650 Specifications

General

Tcase	69.1 °C
Bus type	DMI
FSB Parity	No
Processor cache	8 MB
Processor cores	4
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor codename	Sandy Bridge
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	Realtek ALC269Q HD
Product type	Workstation
Motherboard chipset	Intel® C216
Password protection type	BIOS
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	2 x 4 GB
HDD speed	7200 RPM
RAID levels	0, 1, 5, 10
HDD capacity	500 GB
HDD interface	SATA
Optical drive type	DVD+/-RW
Card reader integrated	-
Graphics card	Quadro 600
External drive bays	2
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card manufacturer	NVIDIA
USB 2.0 ports quantity	7
Parallel ports quantity	0
Chassis type	Tower
Product color	Black
Cable lock slot type	Kensington
Operating system installed	Windows 7 Professional
Certification	CECP, GS
Sustainability certificates	ENERGY STAR
Processor ARK ID	52269
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	435 mm
Width	175 mm
Height	360 mm
Weight	- g
