EXTERNAL CHASSIS VIEWS
FRONT VIEW
1 power button, power light 6
USB 2.0 connectors (2)
2 optical drive bay
(optional)
7 Drive activity light
3
headphone connector
8 optical drive bay
(optional)
4 microphone connector 9 optical drive bay eject
button
5
USB 3.0 connectors (2)
BACK VIEW
10 power supply diagnostic
light
15 security-cable slot
12 power connector
13 back panel connectors
11 power supply diagnostic
button
16 padlock ring
14 expansion card slots (4)
1 PS2/mouse connector 8 PS/2 keyboard
connector
2 network link Integrity
light
9 USB 2.0 connectors (2)
3 network connector 10 DisplayPort connectors
(2)
4 network activity light 11 USB 3.0 connector (2)
BACK PANEL CONNECTORS
5 USB 2.0 connectors (2) 12 VGA connector
6 serial connector 13 Line-in/microphone
connector
7 line-out connector
