Dell S2240T User Manual

10 | About Your Monitor
Monitor Specifications
Flat Panel Specifications
*[S2240T] color gamut (typical) is based on CIE1976 (84%) and CIE1931 (72%) test
standards.
Resolution Specifications
Model S2240T
Screen type Active matrix - TFT LCD
Panel type VA
Viewable image
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
54.6 cm (21.5 inches)
476.64 mm (18.77 inches)
268.11 mm (10.56 inches)
127791.95 mm
2
(198.08 inch
2
)
Pixel pitch 0.248 x 0.248 mm
Viewing angle 178° (vertical) typical
178° (horizontal) typical
Luminance output Panel 280 cd/m² (Typ.)
Monitor 250 cd/m² (Typ.)
Contrast ratio 3000 to 1 (typical)
8M to 1 (typical Dynamic Contrast On)
Faceplate coating Anti-Glare with 3H hardness
Backlight LED edgelight system
Response time 25 ms (typical)
12 ms (typical) with Overdrive
Color depth 16.7 million colors
Color gamut CIE1931 (72%)*
Model S2240T
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 56 Hz to 76 Hz (automatic)
Maximum preset resolution 1920 x 1080 at 60 Hz

Dell S2240T Specifications

General

Color gamut	84 %
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Screen shape	Flat
LED backlight	Yes
Response time	12 ms
Display diagonal	21.5 \
Touch technology	Multi-touch
Touchscreen type	Tabletop
Display brightness	250 cd/m²
Display technology	LED
Supported video modes	1080p
Touchscreen technology	Capacitive
Viewable size diagonal	546 mm
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	54.6 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Number of simultaneous touchpoints	10
Product color	Black, Silver
Glass thickness	1.1 mm
Placement supported	Horizontal
Display viewable area (HxV)	476.64 x 268.11 mm
Dimensions (W x D x H) with stand	522.5 x 77.4 x 382.9 mm
Cables included	AC, HDMI, USB
Tilt angle range	0 - 60 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power supply type	DC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Package weight	6900 g
NVIDIA G-SYNC	No
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	77.4 mm
Width (with stand)	522.5 mm
Height (with stand)	382.9 mm
Weight (without stand)	3400 g
