Dell S2240T User Manual

Operating the Monitor | 29
Using the On-Screen Display (OSD) Menu
Accessing the Menu System
NOTE: If you change the settings and then either proceed to another menu or exit
the OSD menu, the monitor automatically saves those changes. The changes are
also saved if you change the settings and then wait for the OSD menu to disappear.
1. Press the button to launch the OSD menu and display the main menu.
Main Menu for analog (VGA) input
or
Main Menu for digital (DVI) input
or

Dell S2240T Specifications

General

Color gamut	84 %
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Screen shape	Flat
LED backlight	Yes
Response time	12 ms
Display diagonal	21.5 \
Touch technology	Multi-touch
Touchscreen type	Tabletop
Display brightness	250 cd/m²
Display technology	LED
Supported video modes	1080p
Touchscreen technology	Capacitive
Viewable size diagonal	546 mm
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	54.6 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Number of simultaneous touchpoints	10
Product color	Black, Silver
Glass thickness	1.1 mm
Placement supported	Horizontal
Display viewable area (HxV)	476.64 x 268.11 mm
Dimensions (W x D x H) with stand	522.5 x 77.4 x 382.9 mm
Cables included	AC, HDMI, USB
Tilt angle range	0 - 60 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power supply type	DC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Package weight	6900 g
NVIDIA G-SYNC	No
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	77.4 mm
Width (with stand)	522.5 mm
Height (with stand)	382.9 mm
Weight (without stand)	3400 g
