Dell S2240T User Manual

30 | Operating the Monitor
Main Menu for digital (HDMI) input
NOTE: Auto Adjust is only available when you use the analog (VGA) connector.
2. Press the and buttons to move between the setting options. As you move
from one icon to another, the option name is highlighted. See the following table
for a complete list of all the options available for the monitor.
3. Press the button once to activate the highlighted option.
4. Press and button to select the desired parameter.
5. Press to enter the slide bar and then use the and buttons, according
to the indicators on the menu, to make your changes.
6. Select the button to return to the main menu.

Dell S2240T Specifications

General

Color gamut	84 %
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Screen shape	Flat
LED backlight	Yes
Response time	12 ms
Display diagonal	21.5 \
Touch technology	Multi-touch
Touchscreen type	Tabletop
Display brightness	250 cd/m²
Display technology	LED
Supported video modes	1080p
Touchscreen technology	Capacitive
Viewable size diagonal	546 mm
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	54.6 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Number of simultaneous touchpoints	10
Product color	Black, Silver
Glass thickness	1.1 mm
Placement supported	Horizontal
Display viewable area (HxV)	476.64 x 268.11 mm
Dimensions (W x D x H) with stand	522.5 x 77.4 x 382.9 mm
Cables included	AC, HDMI, USB
Tilt angle range	0 - 60 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power supply type	DC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Package weight	6900 g
NVIDIA G-SYNC	No
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	77.4 mm
Width (with stand)	522.5 mm
Height (with stand)	382.9 mm
Weight (without stand)	3400 g
