Dell S2409WFP - Video Supported Modes; Preset Display Modes

* S2409W Color Gamut (Typical) is based on CIE1976 (85%) and CIE1931 (72%).
Resolution
Video Supported Modes
Preset Display Modes
Electrical
Pixel pitch
0.276 mm
Viewing angle
160°(vertical)typical,170°(horizontal)typical
Luminance output
300 CD/m ²(typical)
Contrast ratio
1000 to 1 (typical)
Faceplate coating
Antiglare with hard-coating 3H
Backlight
CCFL edgelight system
Response Time
5 ms typical
Color Gamut
85%*
Horizontal scan range
30 kHz to 83 kHz (automatic)
Vertical scan range
50Hzto76Hz(automatic)
Optimal preset resolution
1920 x 1080 at 60 Hz
Highest preset resolution
1920 x 1080 at 60 Hz
Video display capabilities (DVI playback)
480i/480p/576i/576p/720p/1080i/1080p (Supports HDCP)
Video display capabilities (HDMI playback)
480i/480p/576i/576p/720p/1080i/1080p 
Display Mode
Horizontal
Frequency
(kHz)
Vertical
Frequency (Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal/Vertical)
VGA, 720 x 400
31.5
70.1
28.3
-/+
VGA, 640 x 480
31.5
59.9
25.2
-/-
VESA, 640 x 480
37.5
75.0
31.5
-/-
VESA, 800 x 600
37.9
60.3
40.0
+/+
VESA, 800 x 600
46.9
75.0
49.5
+/+
VESA, 1024 x 768
48.4
60.0
65.0
-/-
VESA, 1024 x 768
60.0
75.0
78.8
+/+
VESA, 1152 x 864
67.5
75.0
108.0
+/+
VESA, 1280 x 1024
64.0
60.0
108.0
+/+
VESA, 1280 x 1024
80.0
75.0
135.0
+/+
VESA, 1920 x 1080
67.2
60.0
173.0
-/+
VESA, 1920 x 1080
66.6
59.9
138.5
+/-
Video input signals
Analog RGB, 0.7 Volts +/- 5%, positive polarity at 75 ohm input
impedance
Digital DVI-D TMDS, 600mV for each differential line, positive
polarity at 50 ohm input impedance
HDMI, 600mV for each differential line, 100 ohm input
impedance per differential pair
Synchronization input signals
Separate horizontal and vertical synchronizations, polarity-free
TTL level, SOG (Composite SYNC on green)
AC input voltage/frequency/current
100 to 240 VAC/50 or 60 Hz + 3 Hz/2.0A (Max.)
Inrush iso surge current
120 V: 30 A (Max.)
240 V: 60 A (Max.)
