Dell SE2717Hc - On-Screen Display (OSD) Menu Navigation

Operating your monitor | 23
Using the on-screen display (OSD) menu
Accessing the OSD menu
NOTE: Any changes you make are automatically saved when you move to
another menu, exit the OSD menu, or wait for the OSD menu to automatically
close.
1.
Press the
button to display the OSD main menu.
Main Menu for analog (VGA) input
Brightness / Contrast
Auto Adjust
Input Source
Color
Display
Energy
Menu
Personalize
Others
Resolution: 1920x1080, 60Hz
Dell SE2717H/HX Energy Use
75% 75%
2.
Press the
and buttons to move between the setting options. As you move
from one icon to another, the option name is highlighted. See the following
table for a complete list of all the options available for the monitor.
3.
Press the
button once to activate the highlighted option.
4.
Press
and button to select the desired parameter.
5.
Press
and then use the and buttons, according to the indicators on
the menu, to make your changes.
6.
Select the
button to return to the main menu.
