Operating your monitor | 29
Display Use the display to adjust image.
Brightness / Contrast
Energy
Menu
Personalize
Others
Resolution: 1920x1080, 60Hz
Dell SE2717H/HX Energy Use
Auto Adjust
Input Source
Color
50
50
50
50
0
Normal
Display
Horizontal Position
Vertical Position
Sharpness
Pixel Clock
Phase
Response Time
Reset Display
Dynamic Contrast
Wide 16:9
Aspect Ratio
Aspect Ratio Adjusts the image ratio to wide 16:9, 4:3 or 5:4.
Horizontal
Position
Use
or the buttons to adjust image left and right.
Minimum is 0 (-). Maximum is 100 (+).
Vertical Position
Use the
or buttons to adjust image up and down.
Minimum is 0 (-). Maximum is 100 (+).
Sharpness This feature can make the image look sharper or softer.
Use
or to adjust the sharpness from 0 to 100.
Pixel Clock The phase and pixel clock adjustments allow you to adjust
your monitor to your preference. Use
or buttons to
adjust for best image quality. Minimum is 0 (-). Maximum
is 100 (+).
NOTE: Applicable when input port is VGA.
Phase If satisfactory results are not obtained using the phase
adjustment, use the pixel clock (coarse) adjustment and
then use phase (fine), again. Minimum is 0 (-). Maximum is
100 (+).
NOTE: Applicable when input port is VGA.
Dynamic
Contrast
Allows you to increase the level of contrast to provide
sharper and more detailed image quality.
Press the
button to select the dynamic contrast on or
off.
NOTE: Dynamic contrast provides higher contrast if you
select game or movie preset mode.
Response Time User can select between Normal, Fast or Super Fast.
Reset Display Select this option to restore default display settings.
