l For hard drive 2:
¡ Remove the three screws that secure the hard drive assembly to the computer base.
¡ Using the pull-tab, lift the hard drive to disconnect the hard drive from the connector on the system board.
¡ Lift the hard drive assembly out of the computer base.
¡ Remove the four screws that secure the hard drive cage to the hard drive.
¡ Pull the interposer to disconnect it from the hard drive.
