Back to Contents Page
 System Board
DellStudio™1745/1747ServiceManual
Removing the System Board
Replacing the System Board
Entering the Service Tag in the BIOS



Removing the System Board

1. Follow the procedures in Before You Begin.

2. Press and eject any installed cards from the ExpressCard slot or the 8-in-1 media card reader.

3. Remove the battery (see Removing the Battery).

4. Remove the base cover (see Removing the Base Cover).

5. Remove the memory module(s) (see Removing the Memory Module(s)).

6. Remove the Mini-Card(s) (see Removing the Mini-Card).

7. Remove the hard drive(s) (see Removing the Hard Drive(s)).

8. Remove the coin-cell battery (see Removing the Coin-Cell Battery).

9. Remove the center control cover (see Removing the Center Control Cover).

10. Remove the keyboard (see Removing the Keyboard).

11. Remove the media controls board (see Removing the Media Controls Board).

12. Remove the palm rest (see Removing the Palm Rest).

13. Remove the Bluetooth card (see Removing the Bluetooth Card).

14. Remove the thermal fan (see Removing the Thermal Fan).

15. Remove the media card reader board (see Removing the Media Card Reader Board).

16. Remove the optical drive (see Removing the Optical Drive).

17. Remove the seven screws that secure the system board assembly to the computer base.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION: Onlyacertifiedservicetechnicianshouldperformrepairsonyourcomputer.DamageduetoservicingthatisnotauthorizedbyDell™
is not covered by your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on your computer).
CAUTION: To help prevent damage to the system board, remove the main battery (see Removing the Battery) before working inside the
computer.
