Dell Studio XPS 435T / 9000 - Replacing the Top Cover

Back to Contents Page
 Replacing the Top Cover
DellStudioXPS™435T/9000ServiceManual


1. Follow the procedures in Before You Begin.

2. Remove the computer cover (see Replacing the Computer Cover).

3. Remove the front panel (see Replacing the Front Panel).

4. Remove the two screws that secure the top cover to the computer.

5. Disconnect the cables from the top I/O panel.

6. Pull the release tab with one hand and slide the top cover away from the chassis.

7. Disconnect the power LED cable from the top cover.

WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at ww.dell.com/regulatory_compliance.
1
top cover
2
screws (2)
3
I/O panel cables


1
power LED cable
2
release tab
