Next steps
1. Connect the battery cable to the connector on the system board.
2. Replace the base cover
3. Replace the SD memory card
4. Follow the procedure in after working inside your computer
VGA Daughterboard
Removing the VGA daughterboard
Prerequisites
1. Follow the procedure in before working inside your computer
2. Remove the SD memory card
3. Remove the base cover
4. Disconnect the battery cable from the connector on the system board.
Steps
1. Disconnect the VGA daughterboard cable from the VGA daughterboard [1].
2. Remove the two (M2x3) screws that secure the VGA daughterboard to the palm rest and keyboard assembly [2].
3. Lift the VGA daughterboard away from the system [3].
36
Removing and installing components
