Dell Vostro 3490 - Power Button; Removing the Power Button

Next steps
1. Replace the display assembly
2. Replace the hard drive assembly
3. Replace the VGA daughterboard
4. Replace the system fan
5. Replace the WLAN
6. Connect the battery cable to the connector on the system board.
7. Replace the base cover
8. Replace the SD memory card
9. Follow the procedure in after working inside your computer
Power button
Removing the power button
Prerequisites
1. Follow the procedure in before working inside your computer
2. Remove the SD memory card
3. Remove the base cover
4. Disconnect the battery cable from the connector on the system board.
5. Remove the WLAN
6. Remove the hard drive assembly
7. Remove the system fan
8. Remove the VGA daughterboard
9. Remove the display assembly
Removing and installing components
55
