Dell Vostro 3490 - Installing the VGA Daughterboard

Installing the VGA daughterboard
Steps
1. Place the VGA daughterboard and align the screw holes on the VGA daughterboard with the screw holes on the palm rest and
keyboard assembly [1].
2. Replace the two (M2x3) screws that secure the VGA daughterboard on the palm rest and keyboard assembly [2].
3. Connect the VGA daughterboard cable to the VGA daughterboard [3].
