Item Ports, panels, or slots Icon Description
4 PCIe expansion card riser
2 (slot 4 and slot 5)
N/A The expansion card riser enables you to connect PCI Express
expansion cards. For more information about the expansion cards
supported on your system, see the Dell VxRail™ P670F, P670N,
V670F, and S670 Technical Specifications.
5 USB 2.0 port (1) This port is USB 2.0-compliant.
6 PCIe expansion card riser
4 (slot 7)
N/A The expansion card riser enables you to connect PCI Express
expansion cards. For more information about the expansion cards
supported on your system, see the Dell VxRail™ P670F, P670N,
V670F, and S670 Technical Specifications.
7 Power supply unit (PSU
2)
For more information about the PSU configurations, see the Dell
VxRail™ P670F, P670N, V670F, and S670 Technical Specifications.
8 VGA port For more information about the VGA, see the Dell VxRail™ P670F,
P670N, V670F, and S670 Technical Specifications.
9 USB 3.0 port (1) This port is USB 3.0-compliant.
10 iDRAC dedicated port Enables you to remotely access iDRAC. For more information, see the
iDRAC User's Guide at www.dell.com/poweredgemanuals.
11 System identification
button
Press the system ID button:
● To locate a particular system within a rack.
● To turn the system ID on or off.
To reset iDRAC, press and hold the button for more than 16 s.
● To reset iDRAC using system ID, ensure that the system ID
button is enabled in the iDRAC setup.
● If the system stops responding during POST, press and hold the
system ID button (for more than 5 s) to enter the BIOS progress
mode.
12 OCP NIC port N/A This port supports OCP 3.0. The NIC ports are integrated on the
OCP card which is connected to the system board.
13 NIC port (1,2) The NIC ports are embedded on the LOM card that is connected to
the system board.
14 Power supply unit (PSU 1) For more information about the PSU configurations, see the on
product documentation page.
For more information about supported drives, see the Dell VxRail™ P670F, P670N, V670F, and S670 Technical Specifications.
Inside the system
The following figure and list contains components inside the system:
System overview
13
