Dell VxRail P670F - Expansion card installation guidelines

Configuration Total No
of
RDIMMs
/
LRDIMM
s
Total No of
Intel
Persistent
Memory
200 series
(BPS)
DIMMs
1 RDIMM/
LRDIMM
capacity
(GB)
1 Intel
Persistent
Memory
200 series
(BPS)
capacity
(GB)
Total
Standard
Memory
Capacity (GB)
Total PM
Capacity
(GB)
Total Memory
(GB)
16 16 16 256 256 4096 4352
16 16 32 256 512 4096 4608
16 16 64 256 1024 4096 5120
16 16 128 256 2048 4096 6144
16 16 16 512 256 8192 8448
16 16 32 512 512 8192 8704
16 16 64 512 1024 8192 9216
16 16 128 512 2048 8192 10240
BPS6 24 4 16 128 384 512 896
24 4 32 128 768 512 1280
24 4 64 128 1536 512 2048
24 4 128 128 3072 512 3584
24 4 16 256 384 1024 1408
24 4 32 256 768 1024 1792
24 4 64 256 1536 1024 2560
24 4 128 256 3072 1024 4096
24 4 16 512 384 2048 2432
24 4 32 512 768 2048 2816
24 4 64 512 1536 2048 3584
24 4 128 512 3072 2048 5120
Expansion card installation guidelines
The following figure shows the expansion card slot connectors:
26
Replacement of hardware components
