Removing the processor
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the right-side cover.
2 Follow the procedure from step 1 to step 2 in “Removing the power-supply unit”.
3 Remove the processor fan and heat-sink assembly.
4 Remove the blower and heat-sink assembly. (if installed)
Procedure
1 Press the processor release-lever down and then pull it outwards to release it
from the securing tab.
2 Extend the processor release-lever completely to open the processor cover.
101
