• Ifyouhaveacasementwindow(gure4)followsteps2&
3andplacethewindowoutletB3outsidethewindowto
exhaustthehotair.
• Ifthewindowsarelarge,usetheadditionalwindowbracket
B5 (ifprovided)tocoveryourwindowaperture,extendingit
totherequiredlength,thenblockingitwiththelockingpins
supplied(seegure5).Makesureyoudonotcoverthehole
forthewindowoutlet.
Forhelpwithinstallation,operation,andforall
accessoriesandspare/replacementparts,pleasecontact
ourtollfreecustomerservicecallcenterat:
1-800-322-3848[USonly]
1-888-335-6644[Canadaonly]
01-800-711-8805(Mexicoonly]
orlogontoourwebsiteat www.delonghi.com
SEMIPERMANENT INSTALLATION
If required, your appliance can also be installed semi-perma-
nently(Fig.6).
min. 11,8 in
min. 30cm
min. 11,8 in
min. 30cm
Proceedasfollows:
• Drillaholeø5,25inches(134mm)inanoutsidewallor
through a window pane. Respect the  dimensions and
heightoftheholegiveningure7and8.
134
Ø 5,25 in.
• FitthewallangeB1intothehole.
• FittheairexhausthoseB2 intherelevanthousinglocated
ontherearsideoftheappliance.(g.1).
• FittheendofthehoseB2 tothewallangeB1 asshownin
g.8.
• WhenthehoseB2isnotconnected,thedrilledholecanbe
closedwiththeangecapB1.
3
4
6
7
inthe
window
panel
inthewooden
kickboard
ofaFrench
window
inthewall:
youare
recommended
toinsulatethe
sectionofwall
usingsuitable
insulation.
