Digital electric
programmer
Temperature knob
(potentiometer)
Door locked
pilot light
Temperature
pilot light
Line
pilot light
Function
selector
GENERAL FEATURES
This oven has special operating features.
5 different functions can be used to satisfy all cooking needs; it also has a pyrolytic
function which can clean the oven cavity at high temperature, a defrost function and
an oven light function.
The functions are managed by an electronic programmer which keeps the temperature
set constant by means of a probe inside the oven cavity.
The oven has the following heating elements:
■ Lower heating element (double) 500+1300 W
■ Upper heating element 1000 W
■ Grill heating element 2000 W
■ Circular heating element 2200 W
MULTIFUNCTION PYROLYTIC OVEN
13
Fig. 3.1
WARNING:
The door is hot, use the handle.
During use the appliance becomes hot. Care should be taken to avoid touching
heating elements inside the oven.
