FITTING THE OVEN INTO A
COLUM
N
The cabinet should have the dimensions
as per fig. 1.7.
Furthermore it is necessary that the
oven is provided with a chimney as per
fig. 1.8.
If the column unit reaches the ceiling an
outlet must be provided through which
air can flow to the outside
Fig. 1.7
Fig. 1.8
WARNING
When correctly installed, your
product meets all safety
requirements laid down for
this type of product category.
However special care should
be taken around the rear or
the underneath of the appli-
ance as these areas are not
designed or intended to be
touched and may contain
sharp or rough edges, that
may cause injury.
