Door assembly
● Grip the door (as indicated in
figure 6.10) and refit it in reverse
order of removing procedure.
Removing the oven door
Please operate as follows:
● Open the door completely.
● The swivel retainers of the rh and
lh hinges (fig. 6.10a) are hooked
onto the metal bar above them
(fig. 6.10b).
● Lift the oven door slightly. The
noch on the bottom of the hinge
will disengage (fig. 6.10c).
● Now pull the oven door forwards
off the appliance. Release both
hinge sections from the slots (fig.
6.10d).
Fig. 6.10
Fig. 6.10a
Fig. 6.10b
Fig. 6.10c
Fig. 6.10d
